Beige ESD Matting 1.0x10m Rolls

Description

Premium, Beige ESD Matting 1.0x10m Rolls, now only £250.00! The KSMLF1MBEI matting is made with a durable, synthetic rubber material. It is comprised of two layers: a static-dissipative surface and a conductive backing, giving a typical resistance to ground of 10⁶-10⁸ ohms. The static-dissipative surface has excellent resistance to abrasion, heat and solder splash. The black, conductive backing provides a superior and consistent ground path to Earth. The material doesn’t melt if in contact with hot metal parts or soldering debris; cheaper PVC based rubber mats are not solder proof.

The KSMLF1MBEI matting has textured, scratch-resistant surface, protecting the surface of static sensitive components during production. The bench matting can be loose-laid at a workstation without the need for any adhesives. Beige ESD Matting 1.0x10m Rolls are fully RoHS and REACH compliant and conform to requirements of EN61340-5-1, BS IEC 61340-5-1, US ESD Associations ANSI S4.1 and S20.20 guidelines, which is the recognised international standards for EPAs.

Product Features :

• Two-layer mat: static-dissipative surface with a conductive backing
• Typical resistance to ground = 10⁶ – 10^{8 ohms}
• Durable, synthetic rubber material
• 1.0 x 10m beige rolls
• 2mm thick
• Textured, scratch-resistant surface
• Easy to clean
• Can be loose-laid at the workbench without adhesives
• Resistant to solder splash, hot paste and abrasion
• No curling, no pin holes, no irritant odour

Specification:

• Thickness: 0.076 (2.00mm)
• Hardness – Upper Dissipative Layer: 70 -5 + 5 shore A (Per ASTM D2240)
• Hardness – Lower Conductive Layer: 75 -5 + 5 shore A (Per ASTM D2240)
• Scratch Resistance: No clear scratch and well recovery
• UV Resistance: No major disc
• Stud Force: 6KG/ 59cm (Recommended)
• Heat Resistance: Resist holds irons and hot paste, rubber doesn’t melt if in contact with hot metal parts and soldering debris
• Charge Decay: < 0.1 sec per FTMS 101C, M4046, TB-WINT-0008
• Charge Generation: < 100 volts per ANSI/ ESD STM4.2
• Room Temperature: 21°C
• Humidity: 62%
• 300% Tensile Strength: top layer – 3.7Mpa,  bottom layer – 3.7Mpa
• Breaking Strength: top layer – 18.7Mpa,  bottom layer – 3.7Mpa
• Elongation at Break: top layer – 690Mpa,  bottom layer – 250Mpa
• Hardness: top layer – 66°,  bottom layer – 80°
• Stud Force: 6KG/ 59cm (Recommended)

Standards & Regulations Compliance:

	IEC-61340-5-1		EN-61340-5-1
	ANSI S4.1 and S20.20 guidelines		CE approved
	RoHS compliant		REACH compliant

*Due to variations in computer monitor displays, colour shown may not be exact.*
